4x8 CNC Router For Sale ATC CNC Router Machines For Wooden Carving
We usually adopt HSD and Hiteco Air Cooling Spindle form Italy. It
has more advantage in work, well known better quality and long
working life-span, good working effect, low ware etc. All these
advantages make it suitable for High-end woodworking engraving
machine, like ATC and single arm type. Of course, it is a good
choice if you wanna a cnc router with faster working speed in
simple engraving operation.
Advantage:
1. Operate easily with many type of coordinate system to set tool
and internal compensation
2. X Y axis adopt rack drive, which make it speed faster and
effective higher, also have all functions of CNC machine 1325
3. Excellent software compatibility can support many kinds of
software, such as TYPE3, ARTCAM,WENTAI et;
4. Has the function of re-carving after break point and power
failure,working time anticipation, preview of tool path simulation, timely correct the error code, back to the
original point with auto correction;
5. Realize many kinds of carving, such as relief carving, shadow
carving, plane carving and cutting;
6. Flexible data get way: Get the data freely with handle, network,
USB flash disk, Can work off-line without resource of computer
7. Handle is connected with computer using USB interface for plug
and play, supporting
WIN91/NT/2000/XP;
8. Whole circuit adopt chain shield cable, which can prevent signal
Interference. Copper core is not easy to break, which improve the stability of machine.
Model | DHRM-2030 |
Spindle | Italy Import Brand Air Cooling Spindle (Optional) |
Inverter | Delta 5.5 KW Inverter |
Max. Rapid Travel Rate | 60000mm/min |
Table Type | T-Slot Table |
Control System | Weihong DSP NK105 Control system |
Optional | Spindle, Control System, Motor and Drivers, Etc |
Syntec Control System
Syntec control system usually adopted in high end CNC router for
multi function. It could be used in ATC CNC router, single arm CNC
router, auto-loading & unloading CNC router, Oscillating knife CNC
router etc.
It is afforable, good with after-sales service, and is currently
the most complete domestic product line, the most potential for
development of professional PC based CNC controller brand.
The operation interface is designed according to human visual sense
system, which makes people's visual sense to reach the most
comfortable state. Portable hand-held remote control unit greatly
facilitates tool setting, test cutting, processing and security.
Servo Motor and Drivers
Compare with stepper motor and driver, Servo motor has lots of good
functions. Better working accuracy, no vibration phenomenon in low
speed, constant torque output in higher speed, strong overload
ability, more reliable and much faster responding speed. Servo
motor and driver is sutable for high end CNC router for higher
request.YASKAWA and Simens is the most popular brand in CNC router
industry.
