Fanuc oi-MF Control System 3 axis CNC Milling Machine Aluminum
Engraving
Advantage
1. Using high rigid structure of cast iron, with resin sand molding
and through aging (tempering process) processing, to ensure the
accuracy of machine tool use for a long time stability, provides
guarantee for the reliability of the machine tool performance;
2. A centralized automatic lubrication device intermittently,
lubrication sufficient and reliable, and can timing quantitative in
three directions of guide rail, screw lubricating points such as
lubrication, just in time to the fuel tank of oil is ok.When the
oil tank is short of oil, the system automatically alarms;
3. The three directions of X, Y and Z are covered by the stainless
steel telescopic shield to ensure the cleaning of the screw and
guide rail, ensuring the transmission and motion accuracy of the
machine tool;
4. X, Y, and Z are in three directions, with high precision and
high strength ball screw, high speed, high positioning accuracy of
machine tool;
5. The outer protection of machine tools is completely closed
structure design, safe and reliable, beautiful and generous;
6. The configuration of machine tool numerical control system,
nanjing opening system, complete function, accuracy and stability,
reliable.
Specifications
| Type | unit | DHVMC-850 |
| Table | Table size | mm | 1000*500 |
| Max. load of worktable | kg | 400 |
| T slot no./width/distance | mm | 18x5x90 |
| Spindle | spindle nose to table surface | mm | 150-650 |
| spidle axis to column surface | mm | 572 |
| Speed Range | rpm | 10,000 |
| Spindle taper | Type | BT-40 |
| Spindle head casing aperture | mm | φ140mm |
| Spindle driver | - | Belt transmission |
| Auto tools change | Maximum tool diameter | mm | Φ80(Φ130) |
| Maximum tool length | mm | 300 |
| Maximum tool weight | kg | 8 |
| Shank | Type | BT-40 |
| Tool magazine capacity | Pieces | 24 |
| Tool exchange method | - | Knife arm |
| Tool exchange time (knife-to-knife) | Sec | 1.8 |
| Rivet | Type | P40-1( 45°) |
| Others | Air source pressure demand | kg/cm | 6 |
| Cutting water tank capacity | L | 250 |
| positioning accuracy | mm | 0.01 |
| Repeatability accuracy | mm | 0.008 |
| Floor area and height | mm | 2550*2250*2400 |
| Machine weight | kg | 5000 |
Machine Details
Auto Chip conveyor
The device has the advantages of serialization, generalization and
standardization, simple operation, reliable operation, convenient
disassembly and assembly, and easy maintenance. It can also be used
in conjunction with other chip evacuation devices to form a variety
of cutting arrangements.
1. It can handle all kinds of chips; it can also be used as a
conveying device for small parts of stamping and cold pier machine
tools.
2. High conveying efficiency and large selection range of conveying
speed;
3. The width of the chain plate is diversified, and the structural
form is divided into two types: a seamless chain plate and a seam
chain plate. 4, streamlined shape, beautiful appearance, smooth
chip removal.
4. With overload protection.
Fanuc servo motor
The FANUC servo is a high-speed, high-precision and high-efficiency
intelligent servo system. The compact structure enables high-speed,
high-precision and energy-saving machine tools.
Nano Control: Rotating extremely smooth servo motor, 32 million/REV
high resolution pulse encoder, high precision current sense servo
amplifier, high speed, high precision servo HRV control
High-speed, high-efficiency: high-speed, high-speed electric
spindle can be realized by winding switching, and the spindle HRV
control with increased speed and fast response can be realized.
Compact body, saves wiring: short body servo and spindle motor,
space-saving thin servo amplifier.
Improve maintenance performance: ID and motor temperature
information for quick maintenance, built-in insulation degradation
detection function, global preventive maintenance.
Hiwin rail
Due to the rolling friction method, when the linear guide is used
as the linear guide, not only the friction coefficient is reduced
to 1/50 of the sliding guide, but also the difference between the
dynamic friction and the static friction is small. Therefore, when
the bed is running, there is no slippage, the positioning accuracy
of μm can be achieved, and the machine can maintain the accuracy
for a long time. The power loss of the machine can be significantly
reduced, and the heat generated by the friction is small, which is
suitable for high-speed operation. The special beam structure
design can bear the load in the up, down, left and right directions
at the same time. Easy to assemble, it maintains accuracy and is
interchangeable, allowing you to replace sliders or rails or even
linear guide sets. The lubrication structure is simple and easy to
oil.
Casting structure,
the whole machine adopts GB300 advanced resin sand castings, and
the internal stress is eliminated by tempering treatment and
vibration and natural aging treatment. One-piece upper water-disc
type wide base, five large parts are mesh internal structure,
bottom ultra-wide "human" shaped column, triangular inverted
T-shaped middle sliding seat, body oil-water separation structure
(pre-water after oil), built-in Pipeline. the body oil and water
separation design, the oblique angle discharge port and the swarf
all aspects design, the rigidity of the body, easy to remove the
chips and the cutting fluid is not easy to smell and leak, and so
on, using the front chip removal method.
Effectively enhance dynamic accuracy and service life.
Full cover shroud
The utility model comprises a lower protective front baffle, a
lower protective left baffle, a lower protective tail baffle, a
lower protective right baffle, an upper protective front panel, an
upper protective left panel, an upper protective rear panel and an
upper protective right panel, the lower protective front The
baffle, the lower protective left baffle, the lower protective
baffle and the lower protective right baffle are sequentially
connected to form a rectangular lower protective frame, the upper
protective front panel, the upper protective left panel, the upper
protective rear panel and the upper protective right The panels are
sequentially connected to form a rectangular upper protective frame
placed on the rectangular lower protective frame and connected to
each other; the upper protective front plate is provided with a
front window, and the front window is provided with a laterally
laterally outer side Door, left inner door, right inner door and
right outer door. The utility model has the advantages of simple
structure, reasonable design, effective protection for the
processing center, convenient opening, and favorable daily
maintenance operation.
